Description
overview
The TP-Link LS1210P PoE+ Switch is a reliable unmanaged desktop switch designed for surveillance systems, small businesses, and office networks that require dependable Power over Ethernet (PoE) connectivity. Equipped with 8 × 10/100 Mbps PoE+ ports and 2 × Gigabit RJ45 uplink ports, it simplifies network deployment by transmitting both power and data over a single Ethernet cable. With a 96W total PoE budget and up to 30W per PoE port, the switch easily powers IP cameras, wireless access points, VoIP phones, and other IEEE 802.3af/at compliant devices.
One of the standout features of the TP-Link LS1210P PoE+ Switch is its Extend Mode, which enables PoE data and power transmission up to 250 meters on ports 1–8. This capability makes the switch an excellent choice for large warehouses, parking areas, campuses, factories, and CCTV surveillance installations where devices are located beyond the standard Ethernet distance. In Extend Mode, transmission speed is adjusted to 10 Mbps to maintain reliable long-distance connectivity.
For enhanced network security, the switch includes Isolation Mode, which separates traffic between PoE ports to prevent unauthorized communication while maintaining access to the uplink. This feature is especially valuable for IP surveillance deployments where camera isolation improves both security and network stability. Additionally, PoE Auto Recovery automatically detects and reboots unresponsive PoE devices, minimizing downtime and reducing maintenance requirements.
The 2 Gigabit uplink ports eliminate bottlenecks by providing high-speed connections to routers, NVRs, or core switches, ensuring smooth traffic aggregation from multiple PoE devices. The fanless metal design delivers silent operation, making the switch suitable for offices, retail stores, schools, hotels, and other noise-sensitive environments. Installation is simple thanks to its true plug-and-play operation, requiring no software configuration or management.
Combining reliable PoE performance, long-range transmission, automatic device recovery, and high-speed uplinks, the TP-Link LS1210P PoE+ Switch is an excellent networking solution for professional surveillance systems and business Ethernet deployments.
Key Features
8 × 10/100 Mbps PoE+ RJ45 ports
2 × 10/100/1000 Mbps Gigabit RJ45 uplink ports
96W total PoE power budget
Delivers up to 30W PoE+ per port (IEEE 802.3af/at)
250m Extend Mode for long-range PoE transmission
Isolation Mode improves network security by isolating PoE ports
PoE Auto Recovery automatically reboots unresponsive powered devices
Plug-and-play operation with no configuration required
Fanless metal housing for silent operation
Desktop or wall-mount installation
Auto MDI/MDIX support
Store-and-Forward switching architecture
IEEE 802.3x Flow Control
Ideal for IP cameras, wireless access points, VoIP phones, and IoT devices
Green Ethernet design for lower power consumption
Technical Specifications
Specification Details
Manufacturer TP-Link
Model LS1210P
Product Type Unmanaged PoE+ Desktop Switch
PoE Ports 8 × 10/100 Mbps RJ45
Uplink Ports 2 × 10/100/1000 Mbps Gigabit RJ45
PoE Standard IEEE 802.3af / IEEE 802.3at
Total PoE Budget 96 W
Max PoE per Port 30 W
Switching Capacity 5.6 Gbps
Packet Forwarding Rate 4.1664 Mpps
MAC Address Table 2K
Packet Buffer 2 Mbit
Jumbo Frame 2 KB
Transmission Method Store-and-Forward
Extend Mode Up to 250 m (Ports 1–8 @ 10 Mbps)
Isolation Mode Supported
PoE Auto Recovery Supported
Network Media Cat3/4/5 (10 Mbps), Cat5 or higher (100 Mbps), Cat5e or higher (1000 Mbps uplinks)
Mounting Desktop / Wall Mount
Cooling Fanless
Dimensions 171 × 98 × 27 mm
Applications
The TP-Link LS1210P PoE+ Switch is ideal for:
IP CCTV surveillance systems
NVR installations
Small and medium businesses
Wireless Access Point deployments
VoIP phone systems
Hotels
Retail stores
Schools and universities
Warehouses
Office buildings
Smart home installations
Long-distance PoE deployments up to 250 meters
Security and access control systems
Why Choose This Product?
The TP-Link LS1210P PoE+ Switch is built for users who need a reliable and affordable PoE switch capable of powering multiple network devices while maintaining simple deployment. Its 8 PoE+ ports provide up to 30W per port with a generous 96W total PoE budget, making it suitable for powering IP cameras, wireless access points, VoIP phones, and other IEEE 802.3af/at devices.
Unlike many entry-level PoE switches, the LS1210P features 2 dedicated Gigabit uplink ports, preventing network bottlenecks when multiple PoE devices transmit data simultaneously. This makes it particularly effective for surveillance systems where several HD IP cameras stream to an NVR.
For professional CCTV deployments, Extend Mode allows power and data transmission up to 250 meters, while Isolation Mode enhances network security by preventing communication between PoE ports. In addition, PoE Auto Recovery automatically detects and restarts unresponsive powered devices, reducing maintenance time and improving system reliability.
Its fanless metal enclosure ensures silent operation and improved durability, making it suitable for offices, retail environments, and other noise-sensitive locations. Combined with true plug-and-play installation, the TP-Link LS1210P PoE+ Switch is an excellent choice for businesses and installers seeking dependable, low-maintenance networking equipment.
Product Comparison
Feature TP-Link LS1210P TP-Link TL-SG1210P
PoE Ports 8 × 10/100 Mbps PoE+ 8 × Gigabit PoE+
Uplink Ports 2 × Gigabit RJ45 1 × Gigabit RJ45 + 1 × Gigabit SFP
Total PoE Budget 96 W 63 W
Max PoE per Port 30 W 30 W
Extend Mode 250 m 250 m
Isolation Mode Yes Yes
PoE Auto Recovery Yes Yes
Best For CCTV & long-range surveillance Gigabit office networks with PoE
Which One Should You Choose?
Choose the TP-Link LS1210P if your priority is long-range CCTV installations, a higher 96W PoE budget, and dual Gigabit uplink ports for connecting to an NVR or core switch.
Choose the TP-Link TL-SG1210P if you need Gigabit connectivity on every PoE port for high-bandwidth devices such as Wi-Fi access points, network storage, or business workstations, while still benefiting from PoE+ functionality.
Frequently Asked Questions (FAQs)
1. What is the TP-Link LS1210P used for?
The TP-Link LS1210P PoE+ Switch is an unmanaged switch designed to provide both power and data over a single Ethernet cable. It is ideal for connecting and powering:
IP CCTV cameras
Wireless Access Points
VoIP phones
IP intercom systems
Access control devices
Other IEEE 802.3af/at PoE-enabled devices
It is especially suitable for surveillance systems and small business networks.
2. How many PoE ports does the TP-Link LS1210P have?
The TP-Link LS1210P features:
8 × 10/100 Mbps PoE+ RJ45 ports
2 × 10/100/1000 Mbps Gigabit RJ45 uplink ports
The Gigabit uplink ports provide fast connections to routers, NVRs, servers, or core switches while the PoE ports power connected devices.
3. What is the total PoE power budget?
The switch provides a 96W total PoE budget, with up to 30W per PoE port in compliance with IEEE 802.3af/at (PoE+) standards.
This is sufficient for powering multiple IP cameras, access points, or VoIP phones simultaneously.
4. What is Extend Mode?
Extend Mode increases the maximum PoE transmission distance from the standard 100 meters to 250 meters on PoE ports.
This feature is ideal for:
Large warehouses
Parking lots
Schools
Office buildings
Long corridors
Outdoor CCTV installations
When Extend Mode is enabled, the affected ports operate at 10 Mbps to ensure stable long-distance communication.
5. What is Isolation Mode?
Isolation Mode prevents communication between PoE ports while still allowing each device to communicate with the uplink ports.
This improves:
Network security
Broadcast storm protection
CCTV network stability
Overall surveillance performance
6. What is PoE Auto Recovery?
PoE Auto Recovery continuously monitors connected PoE devices. If a powered device such as an IP camera stops responding, the switch automatically restarts the PoE port to recover the device without manual intervention.
This helps reduce maintenance time and improves system uptime.
7. Is the TP-Link LS1210P managed?
No.
The TP-Link LS1210P is an unmanaged PoE switch, meaning it works immediately after connecting your devices without requiring software configuration or network management.
8. Who should buy the TP-Link LS1210P?
The TP-Link LS1210P is ideal for:
CCTV installers
Security companies
Small businesses
Retail stores
Hotels
Schools
Offices
Warehouses
Smart building deployments
Anyone needing a reliable long-range PoE switch with Gigabit uplinks
Why Buy from Digital Dreams?
At Digital Dreams, we provide genuine TP-Link networking products backed by expert technical support and competitive pricing across Egypt. Whether you’re deploying a surveillance system, upgrading a business network, or building a reliable PoE infrastructure, we offer authentic TP-Link solutions from an authorized and trusted source.
When you purchase the TP-Link LS1210P PoE+ Switch from Digital Dreams, you receive:
Genuine TP-Link products with manufacturer warranty
Competitive prices across Egypt
Fast nationwide delivery
Professional pre-sales and after-sales technical support
Expert guidance for PoE surveillance and business networking
A complete range of networking products including managed and unmanaged switches, routers, access points, fiber optic solutions, UPS systems, racks, structured cabling, and CCTV accessories
Digital Dreams is your trusted partner for dependable networking and surveillance solutions.
Conclusion
The TP-Link LS1210P PoE+ Switch is a dependable and cost-effective networking solution for surveillance systems and small business deployments. With 8 PoE+ Fast Ethernet ports, 2 dedicated Gigabit uplink ports, a 96W PoE budget, 250-meter Extend Mode, Isolation Mode, and PoE Auto Recovery, it delivers reliable power and data transmission while simplifying installation and maintenance.
Whether you’re powering IP cameras, wireless access points, or VoIP phones, the TP-Link LS1210P offers the performance, durability, and ease of use needed for professional networking projects.
