Description
The TP-Link TL-SG1048 48-Port Gigabit Rackmount Switch is a professional unmanaged network switch designed for enterprise networks, offices, educational institutions, surveillance deployments, data centers, and high-density networking environments requiring reliable Gigabit connectivity. Featuring 48 auto-negotiating 10/100/1000Mbps RJ45 ports, the TL-SG1048 delivers high-speed data transmission across all connected devices while maintaining simple plug-and-play deployment without software configuration.
Built with a durable 19-inch rackmount steel chassis, the switch is ideal for structured cabling environments and network racks. The non-blocking switching architecture provides a 96Gbps switching capacity and 71.4Mpps forwarding rate, ensuring smooth network performance even during heavy traffic loads. Furthermore, TP-Link’s innovative Green Ethernet Technology automatically adjusts power consumption according to link status and cable length, helping businesses reduce operating costs while maintaining network performance. The switch also supports Auto MDI/MDIX and Auto-Negotiation on every port, simplifying installation and eliminating the need for crossover cables. Additionally, the TL-SG1048 supports an 8K/16K MAC address table (depending on hardware version), store-and-forward switching, jumbo frame support up to 12KB, and IEEE 802.3x flow control to ensure reliable and efficient data transmission across large networks. Consequently, the TP-Link TL-SG1048 remains one of the most cost-effective and dependable 48-port Gigabit switches for organizations requiring large-scale network expansion without the complexity of managed switching solutions.
Key Features
48 Gigabit Ethernet Ports — Supports up to 48 wired devices simultaneously with 10/100/1000Mbps connectivity.
96Gbps Switching Capacity — Delivers wire-speed forwarding for high-performance networking.
Plug-and-Play Deployment — No software configuration or management required.
19-Inch Rackmount Design — Perfect for server rooms, racks, and enterprise network cabinets.
Energy-Efficient Technology — Automatically reduces power consumption based on network activity.
Auto MDI/MDIX Support — Eliminates the need for crossover cables.
16K MAC Address Table — Supports large network deployments and device scalability.
IEEE 802.3x Flow Control — Improves network reliability during heavy traffic conditions.
Technical Specifications
Feature Specification / Detail
Brand TP-Link
Model TL-SG1048
Product Type Unmanaged Gigabit Switch
Ports 48 × 10/100/1000Mbps RJ45
Switching Capacity 96Gbps
Packet Forwarding Rate 71.4Mpps
MAC Address Table 16K
Buffer Memory 12Mb
Jumbo Frame Support 12KB
Flow Control IEEE 802.3x
Auto Negotiation Yes
Auto MDI/MDIX Yes
Network Standards IEEE 802.3i, 802.3u, 802.3ab, 802.3x
Power Supply 100-240VAC, 50/60Hz
Maximum Power Consumption 32.3W
Dimensions 440 × 220 × 44 mm
Rackmount Support 19-inch 1U Rackmount
Operating Temperature 0°C to 40°C
Certifications FCC, CE, RoHS
Management Unmanaged
Warranty Manufacturer Limited Warranty
Specifications may vary slightly by hardware revision.
Why Choose the TP-Link TL-SG1048?
The TP-Link TL-SG1048 is designed for organizations that require high port density, dependable Gigabit performance, and straightforward deployment. First, the 48 Gigabit ports allow businesses to connect large numbers of computers, IP phones, printers, access points, cameras, and servers through a single switch.
Furthermore, the unmanaged architecture eliminates the complexity of VLANs, routing, and advanced configuration, making deployment fast and maintenance simple. The switch is particularly suitable for businesses expanding their network infrastructure without requiring advanced Layer 2 management features.
Additionally, the 96Gbps switching fabric ensures smooth data transmission across all ports while the energy-efficient design helps reduce operational costs over time. Community discussions frequently highlight the TL-SG1048 as a cost-effective solution for high-port-count deployments.
Consequently, the TL-SG1048 remains a trusted choice for organizations seeking reliable Gigabit networking at an affordable cost.
Comparison — TP-Link TL-SG1048 vs Typical 48-Port Gigabit Switch
Feature TP-Link TL-SG1048 Typical 48-Port Switch
Ports 48 × Gigabit RJ45 48 × Gigabit RJ45
Switching Capacity 96Gbps 64–96Gbps
Forwarding Rate 71.4Mpps 50–70Mpps
Management Unmanaged Unmanaged
Energy Saving Technology Yes Limited
Auto MDI/MDIX Yes Yes
MAC Address Table 16K 8K–16K
Rackmount Design 1U Rackmount Rackmount
Brand Reliability TP-Link Varies
FAQ — TP-Link TL-SG1048 48-Port Gigabit Rackmount Switch
Q: Is the TL-SG1048 a managed switch?
A: No. The TL-SG1048 is an unmanaged switch designed for plug-and-play deployment without configuration.
Q: Does the switch support Gigabit speeds on all ports?
A: Yes. All 48 RJ45 ports support 10/100/1000Mbps auto-negotiating connections.
Q: Is the switch suitable for CCTV systems?
A: Yes. The TL-SG1048 is widely used in surveillance deployments, office networks, and structured cabling environments requiring many network connections.
Q: Can the switch be rack mounted?
A: Yes. It includes rackmount accessories and fits standard 19-inch network racks.
Q: Does it require any software configuration?
A: No. Installation is completely plug-and-play with automatic port negotiation.
Local Optimization — Egypt Market
The TP-Link TL-SG1048 is highly suitable for Egyptian businesses, schools, hotels, surveillance installations, and enterprise environments that require large-scale Gigabit connectivity. Its 48-port design simplifies structured cabling deployments while minimizing the need for multiple switches.
Furthermore, the switch is commonly deployed in CCTV networks, ISP environments, educational institutions, and corporate offices where reliable Gigabit connectivity is essential. The rackmount form factor integrates easily into standard network cabinets and server rooms, making it an ideal choice for professional installations throughout Egypt.
Additionally, its low power consumption and unmanaged architecture help organizations reduce operational costs while maintaining stable network performance.
Conclusion
The TP-Link TL-SG1048 48-Port Gigabit Rackmount Switch combines 48 Gigabit Ethernet ports, 96Gbps switching capacity, energy-efficient operation, rackmount deployment, and plug-and-play simplicity into a reliable networking solution. Whether used in enterprise networks, surveillance systems, schools, or business environments, the TL-SG1048 provides dependable high-speed connectivity at an excellent value.
