Description
Intel Core i7-13700K Processor 30M Cache, up to 5.40 GHz,16 cores (8 P-cores + 8 E-cores)
16 cores (8 P-cores + 8 E-cores) and 24 threads. Integrated Intel UHD Graphics 770 included
Performance hybrid architecture integrates two core microarchitectures, prioritizing and distributing workloads to optimize performance
Up to 5.4 GHz unlocked. 30M Cache
Compatible with Intel 600 series and 700 series chipset-based motherboards
Turbo Boost Max Technology 3.0, and PCIe 5.0 & 4.0 support. Intel Optane Memory support. No thermal solution included
CPU Specifications
Total Cores : 16
of Performance-cores : 8
of Efficient-cores : 8
Total Threads : 24
Max Turbo Frequency : 5.40 GHz
Intel Turbo Boost Max Technology 3.0 Frequency : 5.40 GHz
Performance-core Max Turbo Frequency : 5.30 GHz
Efficient-core Max Turbo Frequency : 4.20 GHz
Performance-core Base Frequency : 3.40 GHz
Efficient-core Base Frequency : 2.50 GHz
Cache : 30 MB Intel Smart Cache
Total L2 Cache : 24 MB
Processor Base Power : 125 W
Maximum Turbo Power : 253 W
Supplemental Information
Marketing Status : Launched
Launch Date : Q4’22
Embedded Options Available : No
Memory Specifications
Max Memory Size (dependent on memory type) : 128 GB
Memory Types
Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels : 2
Max Memory Bandwidth : 89.6 GB/s
ECC Memory Supported : Yes
Processor Graphics
Processor Graphics : Intel UHD Graphics 770
Graphics Base Frequency : 300 MHz
Graphics Max Dynamic Frequency : 1.60 GHz
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units : 32
Max Resolution (HDMI) : 4096 x 2160 @ 60Hz
Max Resolution (DP) : 7680 x 4320 @ 60Hz
Max Resolution (eDP – Integrated Flat Panel) : 5120 x 3200 @ 120Hz
DirectX* Support : 12
OpenGL* Support : 4.5
OpenCL* Support : 3.0
Multi-Format Codec Engines : 2
Intel Quick Sync Video : Yes
Intel Clear Video HD Technology : Yes
of Displays Supported : 4
Device ID : 0xA780
Expansion Options
Direct Media Interface (DMI) Revision : 4.0
Max of DMI Lanes : 8
Scalability : 1S Only
PCI Express Revision : 5.0 and 4.0
PCI Express Configurations : Up to 1×16+4, 2×8+4
Max of PCI Express Lanes : 20
Package Specifications
Sockets Supported : FCLGA1700
Max CPU Configuration
1TJUNCTION
100°C
Advanced Technologies
Intel Gaussian & Neural Accelerator : 3.0
Intel Thread Director : Yes
Intel Deep Learning Boost (Intel DL Boost) : Yes
Intel Speed Shift Technology : Yes
Intel Turbo Boost Max Technology 3.0 : Yes
Intel Turbo Boost Technology : 2.0
Intel Hyper-Threading Technology : Yes
Intel 64 : Yes
Instruction Set : 64-bit
Instruction Set Extensions
Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States : Yes
Enhanced Intel SpeedStep Technology : Yes
Thermal Monitoring Technologies : Yes
Intel Volume Management Device (VMD) : Yes
Security & Reliability
Intel vPro Eligibility
Intel vPro Enterprise, Intel vPro Essentials, Intel vPro Platform
Intel Threat Detection Technology (TDT) : Yes
Intel Active Management Technology (AMT) : Yes
Intel Standard Manageability (ISM) : Yes
Intel Remote Platform Erase (RPE) : Yes
Intel One-Click Recovery : Yes
Intel Hardware Shield Eligibility : Yes
Intel Control-Flow Enforcement Technology : Yes
Intel Total Memory Encryption – Multi Key : Yes
Intel AES New Instructions : Yes
Secure Key : Yes
Intel OS Guard : Yes
Intel Trusted Execution Technology : Yes
Execute Disable Bit : Yes
Intel Boot Guard : Yes
Mode-based Execute Control (MBEC) : Yes
Intel Stable IT Platform Program (SIPP) : Yes
Intel Virtualization Technology with Redirect Protection (VT-rp) : Yes
Intel Virtualization Technology (VT-x) : Yes
Intel Virtualization Technology for Directed I/O (VT-d) : Yes
Intel VT-x with Extended Page Tables (EPT) : Yes
