Description
The D-Link DGS-F1210-18PS is a professional Layer 2 smart managed Gigabit PoE+ switch designed to meet the growing networking demands of modern businesses, surveillance systems, educational institutions, hospitality environments, and enterprise offices. Equipped with 16 Gigabit PoE+ ports and 2 Gigabit SFP uplink ports, the switch delivers high-speed connectivity, centralized power distribution, and advanced management features in a reliable and cost-effective solution.
Built specifically for IP surveillance and enterprise networking applications, the DGS-F1210-18PS supports a total PoE power budget of up to 150W, enabling users to power multiple IP cameras, wireless access points, VoIP phones, and other PoE-enabled devices directly through Ethernet cables. The switch also features long-range PoE support up to 250 meters, making it an ideal choice for CCTV deployments where devices are installed far from the network cabinet.
In addition to powerful PoE capabilities, the switch includes advanced Layer 2 features such as VLAN, QoS, Link Aggregation, IGMP Snooping, ACL security, and spanning tree protocols including STP, RSTP, and MSTP. These features help optimize traffic flow, improve network security, and maintain stable connectivity for mission-critical business operations.
The D-Link DGS-F1210-18PS is an excellent networking solution for businesses looking for enterprise-grade performance, flexible management, and reliable long-term operation at a competitive price point.
Key Features
16 × 10/100/1000 Mbps Gigabit PoE+ RJ45 ports
2 × Gigabit SFP uplink ports
Total PoE power budget up to 150W
Supports IEEE 802.3af and IEEE 802.3at PoE standards
Long-range PoE transmission up to 250 meters
Layer 2 smart managed switching features
36 Gbps switching capacity
VLAN support for traffic segmentation
Advanced QoS for voice and video prioritization
IGMP Snooping for multicast optimization
Link Aggregation for increased bandwidth
STP/RSTP/MSTP redundancy protocols
ACL security and DHCP Snooping
Web GUI, CLI, SNMP, SSH, and HTTPS management
6KV surge protection for enhanced durability
Energy-efficient and reliable metal design
Technical Specifications
Specification D-Link DGS-F1210-18PS
Switch Type Layer 2 Smart Managed
Total Ports 18 Ports
PoE Ports 16 × Gigabit PoE+ RJ45
Uplink Ports 2 × Gigabit SFP
PoE Standard IEEE 802.3af / 802.3at
Total PoE Budget 150W
Switching Capacity 36 Gbps
Packet Forwarding Rate 23.8 Mpps
MAC Address Table 8K Entries
VLAN Support 802.1Q VLAN
QoS Features 802.1p, DSCP
Security Features ACL, DHCP Snooping, 802.1X
Link Aggregation Supported
Spanning Tree Protocols STP, RSTP, MSTP
Management Options Web GUI, CLI, SNMP, SSH
Long Range PoE Up to 250m
Surge Protection 6KV
Operating Temperature 0°C to 40°C
Housing Metal Chassis
Why Choose D-Link DGS-F1210-18PS?
The D-Link DGS-F1210-18PS offers an ideal combination of performance, management flexibility, and PoE functionality for medium-sized business environments and surveillance projects. Unlike unmanaged switches, this model provides administrators with advanced traffic control, network monitoring, and security management capabilities that improve overall network efficiency.
Its 16 Gigabit PoE+ ports allow simultaneous connection and power delivery to multiple devices without requiring additional power supplies, reducing installation complexity and operational costs. The inclusion of two SFP uplink ports enables high-speed fiber connectivity for backbone integration between switches and network cabinets.
The long-range PoE capability up to 250 meters makes the switch particularly valuable for CCTV installations in warehouses, factories, schools, and outdoor surveillance projects where standard Ethernet distance limitations may create deployment challenges.
Additionally, the DGS-F1210-18PS supports advanced security technologies such as ACL and DHCP Snooping to protect network infrastructure from unauthorized access and malicious traffic. Its enterprise-grade management features make it suitable for organizations seeking stable performance, scalability, and simplified network administration.
Comparison
Feature D-Link DGS-F1210-18PS Huawei S110-16LP2SR TP-Link ES220GMP
Gigabit PoE Ports 16 16 20
SFP Ports 2 2 2
Total PoE Budget 150W 124W 250W
Management Type Smart Managed Unmanaged Smart Managed
VLAN Support Yes Limited Yes
ACL Security Yes No Yes
Link Aggregation Yes No Yes
STP/RSTP Support Yes No Yes
Long Range PoE 250m 250m 250m
Best Use Case Enterprise & CCTV Basic CCTV Systems High-Power SMB Networks
Which Switch Should You Choose?
Choose the D-Link DGS-F1210-18PS if you require advanced Layer 2 management, enterprise-grade stability, and reliable PoE performance for surveillance and office networks.
Choose the Huawei S110-16LP2SR if you need a simple unmanaged PoE switch for smaller CCTV installations.
Choose the TP-Link ES220GMP if your deployment requires a higher PoE power budget and additional powered devices.
Frequently Asked Questions (FAQ)
Does the DGS-F1210-18PS support PoE+ devices?
Yes. The switch fully supports IEEE 802.3af and IEEE 802.3at PoE standards for powering access points, IP phones, and surveillance cameras.
What is the total PoE power budget?
The switch provides a maximum PoE budget of 150W.
Is this switch suitable for CCTV systems?
Absolutely. Its long-range PoE capability up to 250 meters makes it ideal for surveillance deployments.
Does the switch support VLAN configuration?
Yes. The DGS-F1210-18PS supports VLAN segmentation for improved network organization and security.
Can I use fiber uplinks with this switch?
Yes. The switch includes two Gigabit SFP ports for fiber connectivity.
Is this switch managed or unmanaged?
It is a smart managed Layer 2 switch with advanced networking and security features.
Local Optimization (Egypt Market)
The D-Link DGS-F1210-18PS is an excellent solution for the Egyptian market, where businesses increasingly depend on reliable surveillance systems and stable network infrastructure. The switch is especially suitable for hotels, schools, hospitals, offices, factories, retail stores, and commercial buildings throughout Egypt.
Its long-range PoE support is highly beneficial for CCTV projects in large facilities and outdoor installations where cameras are positioned far from the main network room. This helps reduce infrastructure costs and minimizes the need for additional power sources.
For Egyptian system integrators and IT companies, the DGS-F1210-18PS offers a strong balance between affordability and enterprise-level networking features. The switch also supports future network expansion through Gigabit speeds and fiber uplinks, making it a smart long-term investment for growing businesses.
Conclusion
The D-Link DGS-F1210-18PS is a powerful and feature-rich smart managed Gigabit PoE+ switch designed for modern business networking and surveillance applications. With 16 Gigabit PoE+ ports, 2 SFP uplinks, 150W PoE capacity, advanced Layer 2 management, and 250-meter long-range PoE support, the switch delivers excellent reliability, flexibility, and performance.
Whether you are deploying a professional CCTV system, expanding enterprise connectivity, or building a scalable network infrastructure, the DGS-F1210-18PS provides the advanced functionality and dependable operation required for demanding environments. Its combination of affordability, smart management capabilities, and enterprise-grade features makes it one of the best PoE switch solutions available for businesses in Egypt and beyond.
