Description
The GWN7800 series are Layer 2+ managed network switches that allow small-to-medium enterprises to build scalable, secure, high performance, and smart business networks that are fully manageable. It supports advanced VLAN for flexible and sophisticated traffic segmentation, advanced QOS for prioritization of network traffic, IGMP Snooping for network performance optimization, and comprehensive security capabilities against potential attacks
Feature
. The PoE models provide smart dynamic POE output to power IP phones, IP cameras, Wi-Fi access points and other POE endpoints. The series can be managed in a number of ways, including the local network controller embedded in the web user interface of the switch. The series is also supported by GWN. Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform. The enterprise-grade series are the ideal managed network switches for small-to-medium businesses.
key Feature
x Gigabit Ethernet Ports with P0E/POE+ support (IEEE 802.3af/at), 2x Gigabit SFP Ports
Smart power control to support dynamic POE/POE+ power allocation per port
Max. POE Power Budget 120W
Max Output Power per POE Port 30W
Total non-blocking throughput 10Gbps
Switching Capability 20Gbps
Forwarding Rate 14.88M packets per second
Packet Buffer 4.1MB
Forwarding Mode: store-and-forward
Integrated Power Supply 150W
Multicast: IGMP Snooping, MLD Snooping, MVR
DHCP server, DHCP relay, Option 82, 60,160 and 43
1x Console Port
1x tri-color LED for device tracking and status indication,
10x green LEDs for data ports
8x yellow-color LEDs for POE ports
Fan less operation
Desktop/Wall-Mount installation
Operating temperature 0°Cto 45°C, humidity 10-90% RH (Non-condensing)
Storage temperature -10°C to 60°C, humidity: 5% to 95% (Non-condensing)
3 Year Warranty
Show More
Additional information
Access Ports
8
Access Ports Speed
1 G (RJ-45)
Forwarding Rate (Throughput)
14.88 Mpps
Mounting Options
Desktop, Rack Mount
Management Platform
GDMS Networking (Cloud), GWN Manager, Local Web GUI
POE
Support POE
POE Budget
from 100 t0 150 W
Switch Layer
Layer 2+
Switching Capacity
20 Gbps
Uplink Ports
2
UpLinks Speed
1G
